СКУ: PMXETW0100
Partner ETHWAY модул - UNITE сървър, UNITE клиент и общи услуги
-
Brand
Schneider Electric
-
Supporting protocol for SERCOS
FALSE
-
Performance level according to EN ISO 13849-1
EV000494
-
Radio standard GPRS
FALSE
-
Supporting protocol for INTERBUS-Safety
FALSE
-
Supporting protocol for AS-Interface Safety at Work
FALSE
-
Radio standard GSM
FALSE
-
Radio standard UMTS
FALSE
-
Supporting protocol for DeviceNet Safety
FALSE
-
Supporting protocol for Foundation Fieldbus
FALSE
-
Supporting protocol for SafetyBUS p
FALSE
-
Supporting protocol for PROFINET CBA
FALSE
-
Supporting protocol for PROFINET IO
FALSE
-
Supporting protocol for PROFIsafe
FALSE
-
Supporting protocol for ASI
FALSE
-
Radio standard Bluetooth
FALSE
-
Supporting protocol for PROFIBUS
FALSE
-
Radio standard Wi-Fi 802.11
FALSE
-
Supporting protocol for TCP/IP
FALSE
-
Supporting protocol for KNX
FALSE
-
Supporting protocol for CAN
FALSE
-
Supporting protocol for INTERBUS
FALSE
-
IO link master
FALSE
-
Supporting protocol for DeviceNet
FALSE
-
Supporting protocol for Modbus
FALSE
-
Suitable for safety functions
FALSE
-
Supporting protocol for Data-Highway
FALSE
-
Supporting protocol for LON
FALSE
-
Supporting protocol for SUCONET
FALSE
-
Height
97
-
Supporting protocol for other bus systems
FALSE
-
With optical interface
FALSE
-
Number of HW-interfaces parallel
-
Number of interfaces PROFINET
-
Number of HW-interfaces other
-
Number of HW-interfaces serial TTY
-
Number of HW-interfaces Wireless
-
Supporting protocol for EtherNet/IP
TRUE
-
Number of HW-interfaces RS-422
-
Number of HW-interfaces industrial Ethernet
1
-
With potential separation
FALSE
-
Redundancy
FALSE
-
Type of data transmission
EV005799
-
Number of HW-interfaces RS-485
-
Number of HW-interfaces RS-232
-
Width
32
-
Number of HW-interfaces USB
1
-
Transmission rate
10000
-
Depth
104
This ETHWAY module is part of the Modicon X80 range, an offer of common IO modules, communication modules, power supplies, and backplanes for Modicon M340 and Modicon M580 automation platforms. Its power consumption is 1,1A on the 3,3V supply of the bus (peak at 1,7A). It supports 3 types of functions (UNITE Server, UNITE Client and Common Words). Thanks to this module, the Modicon M580 processor can access a subnetwork using a station from its network as a bridge. One ETHWAY module should be installed for each M580 controller that is integrated into the ETHWAY network. This ETHWAY module has dimensions of 32x100x86mm. It allows the Modicon M340 and Modicon M580 processors to communicate with legacy TSX7 and Premium PLCs via the Ethway protocol during a migration campaign. This module is designed by Prosyst, a Schneider Electric TPP partner. This module helps connect the Modicon M580 processor to Premium or TSX Series 7 legacy processors. This Modicon X80 module is to be installed on the X bus rack and fixed with 2 screws. The Modicon range is tailored for easy migration of legacy products. Modicon X80 provides a single environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs.
