СКУ: A9MEM3135
Трифазен електромер KWH 63A с MBUS MID
-
Brand
Schneider Electric
-
Degree of protection (IP)
EV006405
-
Width in number of modular spacings
2
-
Calibrated
TRUE
-
Degree of protection (NEMA)
EV014040
-
Frequency
45
-
Pulse output
EV003671
-
Escapement mechanism
FALSE
-
Accuracy class
EV000074
-
Type of indication
EV005572
-
Mounting method
EV006471
-
With lock code
FALSE
-
Type of meter
EV000101
-
Width
35.8
-
Depth
63
-
Model
EV010942
-
Energy type
EV010946
-
Measurement type load profile
FALSE
-
EEC40 signature
FALSE
-
Suitable for
EV011029
-
Approval
EV010950
-
Pulse type
EV010952
-
Pole type
EV008524
-
Max. current (Imax)
100
-
Tariff control
EV000358
-
Pulse rate
0.01
-
Number of positions total (counter)
7
-
Height
96.71
-
Tariff type
EV009528
-
Nominal current (In)
100
-
Nominal voltage (Un) N-L
195
-
Type of interface
EV007520
The Acti9 iEM3000 series energy meters offer an attractive range of three-phase DIN rail-mounted energy meters with an LCD display. Additional local signaling includes green LED power-on indicator, flashing yellow LED for accuracy checking and communication indicators. This meter can be used in sub-billing and partial metering applications. The meter provides the following accuracy classes: Active Energy: class 1 per IEC 62053-21, Active Energy: class B per EN 50470-3 and Active Energy: class 1 per IEC 61557-12. The meter will measure Active and Reactive Power, Active and Reactive Energy. Designed for 50Hz or 60Hz networks, supply voltage can range from 100 to 277VAC or 173 to 480VAC. Line rated current for this meter is up to 63A direct connect and will support Single Phase and Neutral, Three Phase and Three Phase and Neutral configurations. No primary communication ports. There is one digital pulsed output for energy reading. Certifications include EAC, CE, UL and MID. Product dimensions are as follows: width 3.54 in (90 mm), depth 2.72in (69 mm), height 3.74 in (95 mm) and product weight 9.17 oz (260 g).
